By Fotile

Fotile Inclined Vent Series 30 in. 850 CFM Under Cabinet or Wall Mounted Range Hood in Onyx Black (JQG7522)

Regular price $999.00
Regular price $899.00 Sale price $999.00
Shipping calculated at checkout.
Availability: Out of stock
SKU: JQG7522
Regular price $999.00
Regular price $899.00 Sale price $999.00

Fotile Slant Vent Series, 30 In. wall mount/under-cabinet ducted range hood with Dual-Centrifuge Fan System. Capable of normally producing 530 CFM, but with WhisPower Motor Technology and Capture-Shield extraction, it can achieve a maximum power of 850 CFM and the lowest noise level of 39dB.

With a 90-degree Open Fume Baffle Plate, it captures smoke and fumes before they escape. A large 6 sq. ft. coverage area easily covers all 4/5 burners on your cooktop, guiding smoke upwards and creating a barrier to prevent you from breathing in harmful smoke and grease. Mechanical buttons with Memory Functions keep your preference for fan speed. Color in Onyx Black

Features:

  • 90-degree Always Open Fume Baffle Plate effectively prevents the smoke from spreading in your kitchen and protects you against harm.

  • 30 inches Extra-wide Fume Inlet ensures even suction pressure at every angle, easily covering the cooktop.

  • 6 sq. Ft. Super-large Coverage Area easily covers all the burners on your cooktop.

  • Double Centrifugal Fans ensure strong power and fluent extraction.

  • Super Quiet Operation: Lowest speed has a 39dB noise level; Mid speed has 49dB; High speed has 54dB

  • Memory Function keeps your preference for fan speed.

  • Powerful Lights light up the whole cooking area and help you see the color of the food you are cooking.

  • A large Grease Tray with more volume decreases the frequency of cleaning.

  • The folding Oil Filter is dishwasher safe.

  • Normally, the Open Fume Baffle Plate reduces waiting time and can be used when it's open

Specifications

Product Category: Wall Mount Range Hood and Under Cabinet Range Hood

Dimensions:

29.9 in. W x 18.3 in. D x 17.4 in. H

Weight: 60 lbs

Chimney Dimensions: N/A
Venting Size: 6 in. Duct
Airflow (Q/L/M/H): 220 CFM- 850 CFM
Voltage: 120 V/2.13A/256W
Lighting: LED
Mount Type: Wall Mount or Under Cabinet
Motor: High Performance 1000 CFM/4-Speed Motor
Material: Tempered Glass
Exhaust Vent Location Top
Control Type: Push Button Control
Included: Damper, Filter(s), Power Cord
Certifications: ETL Listed, HVI Certified
Warranty: 5 Years Limited Warranty- first 2 years: Free labor and parts
3rd-5th year, parts only. Lifetime Limited Warranty on Motors
Accessories Guide: Click Here
Specifications Sheet: Click Here
Installation Template:  Click Here
User Manual:  Click Here

Shipping-Return Policy|||


Shipping Lead Times: 5-10 Business Days

Fotile stands behind all products and in the instance that you are dissatisfied with your product, Fotile offers a 30 day return policy. Returns may be subject to restocking fees.


We recommend inspecting your package upon delivery to ensure there is no damage. If there is damage, please take photos of the damage, keep product in it's original packaging, then notify Rustic Customer Service at https://therangehoodstore.com/pages/contact-us.
Please note that Fotile will need to approve the return before Rustic Kitchen and Bath is able to process the return payment.

FOTILE is a premier, high-end global kitchen appliance manufacturer specializing in built-in products designed for healthy, efficient, and technologically advanced cooking. Founded in 1996 by Mao Zhongqun and Mao Lixiang in Ningbo, China, the brand has grown into a global leader trusted by over 30 million families across more than 30 countries, including the United States, Canada, Australia, and Malaysia. FOTILE positions itself as a "Smart Kitchen Expert," blending heavy R&D investment with a brand philosophy focused on family health and well-being.

The brand is world-renowned for its innovative extraction technology. This includes its famous inclined range hoods, side-draft models, and "Butterfly Wing" ring suction systems designed to capture grease and heavy smoke directly at the source before it can disperse.
